1080P Surveillance Camera XMeye Hi3521A 16 Channel 16CH 1080N XVI 5 in 1 Coaxial Hybrid Wifi TVi CVI IP NVR AHD DVR FreeShipping

96 % of buyers enjoyed this product!
Availability: out of stock
Price:
Sale Price:  R0
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

ahd-camera-pciture_01ahd-camera-pciture_02ahd-camera-pciture_03ahd-camera-pciture_04ahd-camera-pciture_05ahd-camera-pciture_06ahd-camera-pciture_07ahd-camera-pciture_08mini-camera_10mini-camera_05mini-camera_06mini-camera_07mini-camera_08

1080P Surveillance Camera XMeye Hi3521A 16 Channel 16CH 1080N 5 in 1 Coaxial Hybrid Wifi TVi CVI IP NVR AHD DVR FreeShipping 01Hisiclion Chip Dahua Exterior Metal Case 16 Channel 1080P,1080N,960P,720P,960H Four in One TVi NVR AHD DVR picture 02AHD DVR Channel type



  • analog:16*1080N;(AHD Camera+TVI Camera+CVI Camera+960H/D1 at same time)
  • hybrid:8*1080N(analog)+8*960P(network)(AHD Camera+TVI Camera+CVI Camera+960H/D1 +IP Camera at same time)
  • Network only:8*1080P;16*960P;4*3M;4*5M



1080N AHD-NH dvr



Q:    What is 1080N AHD-NH DVR?



A:

  1. 1080N AHD-NH Coaxial DVR is new format AHD DVR;
  2. Resolution is 960px*1080px;
  3. Support 2 million pixels(1080P),1.3 million pixels(960P), 1 million(720P) pixels AHD/TVI/CVI Camera; Analog Camera(960H) and IP Cmera(2mp/3mp/5mp).



5-in-1 ahd hybrid dvr

Q:   What is 5-in-1 function?



A:    5-in-1 means that support AHD(AHD Camera),TVI(TVI Camera),CVI(CVI Camera),DVR(analog) and NVR(IP Camera).





1080P Surveillance Camera XMeye Hi3521A 16 Channel 16CH 1080N 5 in 1 Coaxial Hybrid Wifi TVi CVI IP NVR AHD DVR FreeShipping 02

Q:   What is XVI  function?



A:   XVI also known as AXVI (Full name is Advanced XM Video Interface), it is a coaxial transmission video format newest developed by XM. Products with XVI are superior to competitors not only because of its compatibility with AHD,TVI protocols, but also its unique feature.



the advantage of AHD DVR pciture 01

what is ahd dvr

Dvr 4 Channel 1080P,1080N.960P.720P Three in One NVR AHD DVR Combe Picture 03

Hybrid ahd dvr Product Show
Metal Case XMeye 8CH and 4CH 1080P 2MP Full HD Surveillance Video RecorderHybrid 5 in 1 WIFI Onvif NVR TVI CVI AHD DVR Free Shipping 02
2MP Surveillance Camera Xmeye Hi3531A 16CH 16 Channel 5 in 1 Coaxial 1080P WIFI Hybrid NVR CVI TVI AHD CCTV DVR  picture 03
Blue-Ray 1080P,1080N,960P,720P,960H 16CH and 8CH 5 in 1 WIFI Coaxial Hybrid TVI NVR AHD CCTV DVR Surveillance Video Free Shipping 04





Hisiclion Chip Dahua Exterior Metal Case 16 Channel 1080P,1080N,960P,720P,960H Four in One TVi NVR AHD DVR interface picture



16CH 5-in-1 DVR Screenshots:

16 channnels 16ch ahd dvr interface picture



16CH 5-in-1 DVR Menu:

IMG_20160928_111419_BURST001_COVER



IMG_20160928_111244



16CH 5-in-1 DVR Singal:

five in one ahd tvi cvi dvr picture



16CH 5-in-1 DVR Language:

dvr languages



five in on ahd tvi cvi nvr dvr Language picture 02



16CH 5-in-1 DVR Channel Type:

16 channnels 16ch ahd dvr  channel type picture

basic parameters picture

  • Support VGA, HDMI full HD output simultaneously;
  • Support ONVIF; access third party;
  • Support AHD, TVI ,CVi HD video input;
  • Support Web, CMS, center platform management software MYEYE, provide SDK development;
  • Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;
  • Support various mobile monitoring (iPhone, Android);
  • Remote Access, With DNS (ARSP),easy to monitor remotely
  Model 6016T-LM(D)
System  Main processor processor   Hi3521A
Interface  Preview  1/4/8/9/16
Video  Codec H.264
Monitor quality   VGA,HDMI:HD
Encode ability 16*1080N
Decode ability  16*1080N
Onvif  support support
Multi-mode input analog: 16*1080N;8*1080N;
hybrid: 8*1080N(analog)+8*960P(network);Network only:8*1080P;16*960P;4*3M;4*5M
Motion Detection Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel)
Audio Audio compression   G.711A
Intercom   support
Record & playback Record mode   manual>alarm>motion detection>timing
Local Playback   16ch(local input mode)
Search mode   Search by time, calendar, event, channel
Storage & backup Video storage   HDD, network
Backup mode   Network, USBhard disk, USB burner, SATA burner
External Interface Video output 1ch VGA, 1ch HDMI
Loop Vout   N/A
Audio I/O   2(Can be extended to 6ch)/1
Alarm I/O  0(Can be extended to 4ch)/0(Can be extended to 1ch)
Network interface   RJ45 10M/100M self-adaption
PTZ control 1*RS485, Support kinds of PTZ protocols
USB 2* USB 2.0 ports
HDD 1*SATA ports (Max 6TB/per)
Wireless   3G, WIFI (extend via USB)
General  Power supply   12V/3A
Power Consumption   <15W (without HDD)
Working environment Temperature:0 degree – +55 degree Humidity:10%-90%,Atm:86kpa-106kpa
Dimension(mother board) 235mm*90mm
Weight(mother board) 279g





Notice:

if you want use 2pcs hard disk about this dvr, please click this link for buy 2*SATA Port  16 channel hybrid AHD DVR, Thanks!

click here buttonhd buy now button



Hybrid AHD DVR shipping time and ways



  • 1.Russian Federation: 7-22 days By RETS-Express

  • 2.Brazil: 15-30 days E-Packet

  • 3.East Asia (Japan and Korea): 7-15 days EMS or E-Packet

  • 4.Southeast Asia: 7-15 days E-packet or Singapore Post

  • 5.Central Asia and South Asia: 7-20days China post

  • 6.West Asia (Israel): E-Packet; Netherlands Post; Swiss Post, about 7-15 days

  • 7.United States and Canada: 3-7 days DHL

  • 8.Europe: E-Packet; Netherlands Post; Swiss Post, about 7-15 days

  • 9.Oceania (Australia and New Zealand): 7-15 days E-Packet



we only spent two days (48 hours)  for sent parcel , have tracking number and tracking number information,Thanks!



Friendly Reminder:



         if you want us sent goods quickly that use DHL,UPS,FedEx,ARAMEX and so on.Please connect US by leave me a message in Aliexpress.We will calculate extra shipping Cost for you and adjust price for your order,Thanks!(becuase of different custom policy of many country, If you want avoid high custom tax, i can declare a low price for goods with your request,i often delcare $18 for this 16ch hybrid dvr,Thanks! )





Notice:



If you want to use WIFI function , please click the following button to buy USB WIFI Antenna Module,Thanks!



click here buttonhd buy now button

XMeye Hi3521A 16 Channel 16CH 1080N 5 in 1 Coaxial Hybrid Wifi TVi CVI IP NVR AHD DVR picture 05



  Power Adapter Standard

12V 1A Power adpatar

 1080P Surveillance Camera XMeye Hi3521A 16 Channel 16CH 1080N 5 in 1 Coaxial Hybrid Wifi TVi CVI IP NVR AHD DVR FreeShipping

 XM ahd dvr and cctv camera remote control by computerand phone

 factory pciturefactory certification

11

NOTICE:

     if you have any question about this Video Recorder and Logistics,Contact us in the above manner,we will try our best to help you,if you input dispute or give negative feedback without responsible ,we not welcome unfriendly client,Thanks!

ahd camera and dvr gifts

123

ahd-CCTV-dvr_01ahd-CCTV-dvr_02ahd-CCTV-dvr_03ahd-CCTV-dvr_04ahd-CCTV-dvr_05ahd-CCTV-dvr_06ahd-CCTV-dvr_07ahd-CCTV-dvr_08ahd-CCTV-dvr_09ahd-CCTV-dvr_10ahd-CCTV-dvr_11ahd-CCTV-dvr_12

Shipping Company Shipping Cost Estimated Delivery Time
DHL 3 - 7 days
UPS Expedited 3 - 7 days
EMS 5 - 14 days
Post Air Mail Free Shipping 15 - 45 days
Return Policy If the product you receive is not as described or low quality, the seller promises that you may return it before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe) and receive a full refund. The return shipping fee will be paid by you. Or, you can choose to keep the product and agree the refund amount directly with the seller.

N.B.: If the seller provides the "Longer Protection" service on this product, you may ask for refund up to 15 days after order completion.
Seller Service On-time DeliveryIf you do not receive your purchase within 60 days, you can ask for a full refund before order completion (when you click "Confirm Order Received" or exceed confirmation timeframe).
