Hikvision Video Access Control-DS-KV8202-1A(DS-KV8202-IM),120 WDR camera,Visual intercom doorbell,IC card to open the door

0 % of buyers enjoyed this product!
Availability: out of stock
Sale Price:  R0
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days
Mobile APP:Hik-connect (The WIFI of the indoor monitor must be activated)

APP Support multi language;

When the outdoor  station access to HIKVISION NVR, and the light is relatively dark, IR light in the outdoor station will be auto opened,Provide lighting for NVR recording,and every 30 minutes to test a brightness.(The base version does not have this feature.)

When someone pushes the button of outdoor station,you can receive information on your mobile phone,you can use the phone to unlock door/Electric door closer,and answer/hang up the video;

The outdoor station can access to HIKVISION NVR,and it can live view,record,playback.
You can swipe card on the outdoor station to unlock,can also swipe card to HIKVISION 485 card reader.
If you use 2/4-button outdoor station, indoor monitors support video dialogue among each room number,For example 101 call 201,101 call 301,201 call 301,and if indoor monitor has a camera,Each room can see each other’s video images.;
If you use one-button outdoor station,and you have more than one indoor monitor,Master indoor monitor and Slave indoor monitor can’t support video dialogue between them,becuse there is only one room number.
The indoor monitor can take a sub video stream from HIKVISION camera,without time limit!(The base version does not have this feature.)
DS-KH8301-WT/DS-KH8501-WT can insert TF memory card, support video recode and playback video;
The indoor monitor has the function of Alarm input and Alarm output,and it can connect to Infrared alarm detectors, smoke detectors, gas detectors, magnetometer sensor,and it can connect to Acousto-optic alarm;
When the indoor monitor alarms,it can push information to your phone.
The indoor monitor can control opening Electric Lock and Hikvision fingerprint/smart lock;
Cabin bottom box, IC card entrance guard read head, 1.3 million pixels wide dynamic 120 ° wide Angle lens Single button the door machine, the machine can achieve the call more indoor machine model, or more than the door machine call many sets of indoor machine model, support the door machine directly authorized user card, call captured images, control of electric locks the door machine support. Can be added to the hik NVR video directly
System parameters
High-performance embedded processor SOC processors
Operating system, embedded Linux operating system
Video parameters
130 w pixel cameras, CMOS low illumination high-definition color video camera
Video compression standard h. 264
1280 * 720 resolution
Video frame rate of 25 frames per second
Mend a light infrared light
Audio parameters
Built-in audio input all point to the microphone
Audio output built-in speakers
The audio compression standard g. 711 u
Audio compression bit rate of 64 KBPS
Sound quality support for noise suppression and echo cancellation
Access control parameters
Built-in card reader built-in IC card reading head
Door magnetic detection can detect door magnetic switch state
Through the open button to open the door open button
Normally open normally closed support setting normally open/closed
Network parameters
10 m / 100 m Ethernet adaptive
The network protocol TCP/IP, SNMP, SIP, RTSP
Alarm parameters
Alarm input tamper, door magnetic detection
Device interface
So a RJ45 10 m / 100 m adaptive Ethernet front-end ports
1 RS485 interface RS485 full-duplex
IO input 4
IO output 1
The work environment
Working temperature and 40 ~ 70(degree centigrade
Working humidity 10% to 90%
The power consumption of 10 or less w
DC12V power supply
The other parameters
Degree of protection IP65
Overall dimensions 182 mm * 100 mm * 32.5 mm
